Gas And Light Oil Burner BNGL 35/50/85 P

  Dual Fuel Burners     |      2023-11-03 16:01

dual fuel light oil and gas burner

BNGL 35/50/85 P  Technical Performance

1. Alternate methane gas/light oil burner.

2. Two-stage operation (high/low flame).

3. Air-gas mixing at blast-pipe and high pressure mechanical atomisation of fuel using nozzle.

4. Ability to obtain optimal combustion values by regulating combustion air and blast-pipe.

5. Maintenance facilitated by the fact that the mixing unit and the atomisation unit can be removed without having to remove the burner from the boiler.

6. Maintenance facilitated by the fact that the mixing unit and the atomisation unit can be removed without having to remove the burner from the boiler.

7. Equipped with one flange and one insulating seal for boiler fastening.

8. Combustion air intake with air flow adjustment device.

9. Sliding boiler coupling flange to adapt to head protrusion of the various types of boilers.

10. Sliding boiler coupling flange to adapt to head protrusion of the various types of boilers.

11. UV ultraviolet phototube detects flame.

12. Electrical plant protection rating lP40.
