The gas burner structure consists of the following 5 systems:

 News     |      2022-12-30 11:42
1. Air supply system
The function of the air supply system is to send air with a certain wind speed and light volume into the combustion chamber. Its main components are: housing, fan motor, fan impeller, air gun fire tube, damper controller, damper baffle, cam adjustment mechanism Diffuser disc.
2. Ignition system
The function of the ignition system is to ignite the mixture of air and fuel. Its main components are: ignition transformer, ignition electrode, and electric ignition high-voltage cable.
3. Monitoring system
The function of the monitoring system is to ensure the safe and stable operation of the burner. Its main components include flame monitors, pressure monitors, and temperature monitors.
4. Fuel system
The function of the fuel system is to ensure the fuel required for the burner to burn. The fuel system of the oil burner mainly includes: oil pipes and joints, oil pumps, solenoid valves, nozzles, and heavy oil preheaters. Gas burners mainly include filters, pressure regulators, solenoid valves, ignition solenoid valves, and fuel butterfly valves.
5. Electric control system
The electronic control system is the command center and contact center of the above systems. The main control element is the program controller, which is equipped with different program controllers for different burners. The common program controllers are: LFL series, LAL series, LOA series, LGB series , the main difference is that the time of each program step is different.
